Space Considerations for Truck Equipment
When selecting air compressor systems for trucks, it’s important to consider space limitations. Systems like VMAC’s Underhood 70, which fit under the engine hood, are lighter and can save room on the truck’s deck or cargo area.
The Demand for Storage
A significant factor in the design of Miller Electric’s latest products was the technicians’ need for storage. “Technicians often prefer to take all necessary tools into the field to complete their jobs efficiently,” states Andy Baus, product manager for work truck solutions at Miller Electric.
Challenges of Overloading Trucks
However, overloading can lead to issues with the vehicle’s chassis and body, alongside restrictions regarding gross vehicle weight. If a technician isn’t a CDL driver, fleet managers may need to consider smaller truck options, which could restrict the space available for equipment.
All-in-One Solutions
One solution to this issue is all-in-one systems. By integrating the compressor and welder/generator into a single unit, these systems offer a lighter and more compact alternative.
Miller’s HDI Air Pak Series
An example is Miller’s HDI Air Pak Series, which stands for hydraulically driven and integrated. This compact design can reduce the footprint of equipment by up to 50% and can cut weight by 400 to 500 pounds.
Specifications and Compatibility
The HDI Air Pak models feature a rotary screw air compressor, multi-process welder, battery charger/crank assist, and auxiliary power sources. Each model is tailored to help fleet managers align performance specifications with typical service truck requirements, delivering 40 or 58 CFM at 100 psi and 265 or 325 amps for stick or TIG welding. The Model 265 is suited for Class 5 chassis, requiring 11 gpm hydraulic flow, while the Model 325 is a better match for Class 6-8, needing 16 gpm.
VMAC’s Multifunction System
VMAC also provides all-in-one options, such as its 6-In-1 Multifunction Power System, which comes with a 45-cfm rotary screw air compressor and a 250-amp welder.
Making the Right Choice
The decision between a multifunction system and a traditional multi-piece setup hinges on the desired truck configuration and the technician’s routine tasks. By understanding these factors, equipment managers can make informed choices that enhance technician efficiency while managing capital costs.
